Introduction
A traditional agitation equipment
Effective Volume
0.074～19.1m3
Product Improvement
The creator of lining BaoShan wear- resistant rubber on cylinder
The cylinder is lined with Baoshan wear-resistant rubber with strong resistance to wear and corrosion
Strong agitation capability
Stable operation, convenient maintenance
Energy saving
Product application
Agitation tank is mainly applied in slurry stirring before flotation, chemical and construction industry, cyanide chemical plant, sewage treatment plant, and coal plant etc.
（Better using according to the own situation and guidance of technician）
|
Model |
Effective Volume (m3) |
Rotating Speed of Impeller (r/min) |
Diameter of Impeller (mm) |
Motor Model |
Motor Power |
Weight |
|
BJ-500X500 |
0.0785 |
493 |
160 |
Y80L-4 |
0.55 |
120 |
|
BJ-750X750 |
0.25 |
530 |
240 |
Y100L-6 |
1.5 |
240 |
|
BJ-1000X1000 |
0.58 |
530 |
310 |
Y100L-6 |
1.5 |
680 |
|
BJ-1500X1500 |
2.2 |
320 |
400 |
Y132S-6 |
3 |
790 |
|
BJ-1600X1800 |
2.6 |
331 |
400 |
Y132M2-6 |
5.5 |
990 |
|
BJ-2000X2000 |
4.4 |
230 |
550 |
Y132M2-6 |
5.5 |
1800 |
|
BJ-2000X2500 |
5.9 |
230 |
630 |
Y160M-6 |
7.5 |
2106 |
|
BJ-2500X2500 |
11.2 |
230 |
630 |
Y160M-6 |
7.5 |
2766 |
|
BJ-3000X3000 |
19.1 |
210 |
700 |
Y225S-8 |
18.5 |
4613 |
|
BJ-3500X3500 |
24 |
230 |
850 |
Y225M-8 |
22 |
5980 |
|
BJ-4000 X 4000 |
45 |
153 |
1000 |
Y250M-8 |
30 |
8910 |
